| Manufacturer Part Number: | ELK204-7T-USB-WB-PL |
|---|---|
| Manufacturer: | Matrix Orbital |
| Product Category: | Display Modules - LCD, OLED Character and Numeric |
| Available Quantity: | 9011 Pieces |
| Unit Price: | Quote by Email |
| Description: | Character LCD Display Module Transmissive 5 x 7 Dots TN - Twisted Nematic LED - Blue USB 153.30mm x 49.30mm x 35.10mm |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ELK204-7T-USB-WB-PL Datasheet |
| Internal Part Number | 898-ELK204-7T-USB-WB-PL | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | ELK Series Displays | |
| Online Catalog | Enclosure Series | |
| Category | Optoelectronics | |
| Family | Display Modules - LCD, OLED Character and Numeric | |
| Manufacturer | Matrix Orbital | |
| Series | Enclosure Series | |
| Part Status | Active | |
| Number of Characters | 80 | |
| Display Format | 20 x 4 | |
| Character Format | 5 x 7 Dots | |
| Display Type | TN - Twisted Nematic | |
| Display Mode | Transmissive | |
| Character Size | 5.15mm H x 3.20mm W | |
| Outline L x W x H | 153.30mm x 49.30mm x 35.10mm | |
| Viewing Area | 82.50mm L x 28.90mm W | |
| Backlight | LED - Blue | |
| Voltage - Supply | 4.75 V ~ 5.25 V | |
| Dot Size | - | |
| Interface | USB | |
| Operating Temperature | 0°C ~ 50°C | |
| Text Color | White | |
| Background Color | Blue | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ELK204-7T-USB-WB-PL | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ELK204-7T-USB-WB-PL is in stock for immediate shipping now. We are the distributor of Matrix Orbital all series components. The condition of ELK204-7T-USB-WB-PL is new and unused, you can buy ELK204-7T-USB-WB-PL Matrix Orbital with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ELK204-7T-USB-WB-PL.
