ELFB12280

ELFB12280
Manufacturer Part Number:ELFB12280
Manufacturer:
Product Category:Terminal Blocks - Headers, Plugs and Sockets
Available Quantity:9131 Pieces
Unit Price:Quote by Email
Description:12 Position Terminal Block Header, Female Sockets 0.200" (5.08mm) Vertical Through Hole
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: ELFB12280 Datasheet
ELFB12280´s Parameters
Internal Part Number898-ELFB12280
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Online Catalog ELF Series
CategoryConnectors, Interconnects
FamilyTerminal Blocks - Headers, Plugs and Sockets
ManufacturerAmphenol PCD
SeriesELFB
PackagingBulk
Part StatusActive
TypeHeader, Female Sockets
Number of Positions12
Positions Per Level12
Number of Levels1
Pitch0.200" (5.08mm)
Header OrientationVertical
Plug Wire Entry-
Termination StyleSolder
Mounting TypeThrough Hole
Current - IEC-
Voltage - IEC-
Current - UL15A
Voltage - UL300V
Wire Gauge or Range - AWG-
Wire Gauge or Range - mm²-
ColorBlack
Operating Temperature125°C
Contact Mating FinishTin
FeaturesInterlocking (Side), Retention Latches
Standard Package 100
Weight0.001 KG
ApplicationEmail for details
Replacement PartELFB12280
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

ELFB12280 is in stock for immediate shipping now. We are the distributor of Amphenol PCD all series components. The condition of ELFB12280 is new and unused, you can buy ELFB12280 Amphenol PCD with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for ELFB12280.
