| Manufacturer Part Number: | EL5525IREZ-T13 |
|---|---|
| Manufacturer: | Intersil |
| Product Category: | PMIC - Voltage Regulators - Special Purpose |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | - Converter, TFT LCD Voltage Regulator IC 18 Output 38-HTSSOP |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | EL5525IREZ-T13 Datasheet |
| Internal Part Number | 898-EL5525IREZ-T13 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 19/Nov/2012 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Special Purpose | |
| Manufacturer | Intersil | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Obsolete | |
| Applications | Converter, TFT LCD | |
| Voltage - Input | 4.5 V ~ 16.5 V | |
| Number of Outputs | 18 | |
| Voltage - Output | 0.5 V ~ 14.95 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 38-TFSOP (0.173", 4.40mm Width) Exposed Pad | |
| Supplier Device Package | 38-HTSSOP | |
| Standard Package | 2,500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | EL5525IREZ-T13 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
EL5525IREZ-T13 is in stock for immediate shipping now. We are the distributor of Intersil all series components. The condition of EL5525IREZ-T13 is new and unused, you can buy EL5525IREZ-T13 Intersil with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for EL5525IREZ-T13.
