EJ502B

EJ502B
Manufacturer Part Number:EJ502B
Manufacturer:
Product Category:Barrel - Power Connectors
Available Quantity:9184 Pieces
Unit Price:Quote by Email
Description:DC JACK SLD PINS CHASSIS 2.5MM
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: EJ502B Datasheet
EJ502B´s Parameters
Internal Part Number898-EJ502B
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Featured Product2.1 mm x 5.5 mm or 2.5 mm x 5.5 mm DC Jacks
Online Catalog MPD (Memory Protection Devices)
CategoryConnectors, Interconnects
FamilyBarrel - Power Connectors
ManufacturerMPD (Memory Protection Devices)
Series-
PackagingBulk
Part StatusActive
Connector TypeJack
GenderMale
Industry Recognized Mating Diameter2.50mm ID (0.098"), 5.50mm OD (0.217")
Actual Diameter0.098" (2.50mm ID), 0.220" (5.60mm OD)
Number of Positions/Contacts2 Conductors, 3 Contacts
Internal Switch(s)Single Switch, Normally Closed
Mounting TypeChassis Mount
Mounting FeatureBulkhead - Front Side Nut
TerminationSolder Eyelet(s)
ShieldingUnshielded
Features-
Insulation Color-
Voltage - Rated12VDC
Current Rating5A
Mating Length/Depth-
Contact Material - PlatingSilver
Body MaterialBrass
Operating Temperature-
Includes3 pcs - 1 Connector, 1 Nut, 1 Washer
Standard Package 100
Weight0.001 KG
ApplicationEmail for details
Replacement PartEJ502B
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

EJ502B is in stock for immediate shipping now. We are the distributor of MPD (Memory Protection Devices) all series components. The condition of EJ502B is new and unused, you can buy EJ502B MPD (Memory Protection Devices) with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for EJ502B.
