Manufacturer Part Number: | ECS-LVDS25-1562.5-A |
---|---|
Manufacturer: | ECS Inc. |
Product Category: | Oscillators |
Available Quantity: | 9510 Pieces |
Unit Price: | Quote by Email |
Description: | 156.25MHz LVDS XO (Standard) Oscillator Surface Mount 2.5V 70mA Enable/Disable |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | ECS-LVDS25-1562.5-A Datasheet |
Internal Part Number | 898-ECS-LVDS25-1562.5-A | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Online Catalog | ECS-LVDS25 and ECS-LVDS33 Series | |
Category | Crystals and Oscillators | |
Family | Oscillators | |
Manufacturer | ECS Inc. | |
Series | ECS-LVDS25 | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Type | XO (Standard) | |
Frequency | 156.25MHz | |
Function | Enable/Disable | |
Output | LVDS | |
Voltage - Supply | 2.5V | |
Frequency Stability | ±100ppm | |
Operating Temperature | 0°C ~ 70°C | |
Current - Supply (Max) | 70mA | |
Ratings | - | |
Mounting Type | Surface Mount | |
Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) | |
Height | 0.067" (1.70mm) | |
Package / Case | 6-SMD, No Lead (DFN, LCC) | |
Current - Supply (Disable) (Max) | 30µA | |
Standard Package | 500 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | ECS-LVDS25-1562.5-A | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
ECS-LVDS25-1562.5-A is in stock for immediate shipping now. We are the distributor of ECS Inc. all series components. The condition of ECS-LVDS25-1562.5-A is new and unused, you can buy ECS-LVDS25-1562.5-A ECS Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ECS-LVDS25-1562.5-A.
