| Manufacturer Part Number: | E6486 |
|---|---|
| Manufacturer: | Atmel |
| Product Category: | Evaluation Boards - Sensors |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | QT60326, QT60486 Quantum, QMatrix™ Touch, Capacitive Sensor Evaluation Board |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | E6486 Datasheet |
| Internal Part Number | 898-E6486 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Video File | Introducing Atmel Studio 7 | |
| Design Resources | Development Tool Selector | |
| PCN Obsolescence/ EOL | Multiple Devices 21/Jan/2014 | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - Sensors | |
| Manufacturer | Atmel | |
| Series | Quantum, QMatrix™ | |
| Part Status | Obsolete | |
| Sensor Type | Touch, Capacitive | |
| Sensing Range | 32 / 48 Buttons/Keys | |
| Interface | RS-232 | |
| Sensitivity | - | |
| Voltage - Supply | 4.75 V ~ 5.25 V | |
| Embedded | No | |
| Supplied Contents | Board | |
| Utilized IC / Part | QT60326, QT60486 | |
| Standard Package | 3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | E6486 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
E6486 is in stock for immediate shipping now. We are the distributor of Atmel all series components. The condition of E6486 is new and unused, you can buy E6486 Atmel with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for E6486.
