| Manufacturer Part Number: | DWR-T820P-R233-B2 |
|---|---|
| Manufacturer: | Amphenol Commercial Products |
| Product Category: | Backplane Connectors - Specialized |
| Available Quantity: | 9031 Pieces |
| Unit Price: | Quote by Email |
| Description: | CONN HEADER 28POS RA PCB |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DWR-T820P-R233-B2 Datasheet |
| Internal Part Number | 898-DWR-T820P-R233-B2 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | DWR, CoolPower® Series | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - Specialized | |
| Manufacturer | Amphenol Commercial Products | |
| Series | DWR, CoolPower® | |
| Packaging | Tray | |
| Part Status | Active | |
| Connector Usage | Backplane | |
| Connector Type | Plug, Male Pins | |
| Connector Style | Drawer | |
| Number of Positions | 28 | |
| Number of Positions Loaded | All | |
| Pitch | 0.108" (2.74mm) | |
| Number of Rows | 2 | |
| Number of Columns | - | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder | |
| Contact Layout, Typical | 20 Signal, 8 Power | |
| Features | Board Lock, Guide Pin | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Color | Black | |
| Current Rating | - | |
| Material Flammability Rating | - | |
| Operating Temperature | -55°C ~ 105°C | |
| Voltage Rating | - | |
| Standard Package | 20 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DWR-T820P-R233-B2 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DWR-T820P-R233-B2 is in stock for immediate shipping now. We are the distributor of Amphenol Commercial Products all series components. The condition of DWR-T820P-R233-B2 is new and unused, you can buy DWR-T820P-R233-B2 Amphenol Commercial Products with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DWR-T820P-R233-B2.
