| Manufacturer Part Number: | DV164039 |
|---|---|
| Manufacturer: | Microchip Technology |
| Product Category: | Evaluation Boards - Embedded - MCU, DSP |
| Available Quantity: | 9013 Pieces |
| Unit Price: | Quote by Email |
| Description: | PIC24FJ256DA210 PIC24FJ256DA210 Development Kit PIC® MCU 16-Bit PIC Embedded Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DV164039 Datasheet |
| Internal Part Number | 898-DV164039 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Intro to PIC24FJDA Family | |
| Video File | PIC24FJ256DA210 Development Board Overview | |
| Design Resources | Development Tool Selector | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Online Catalog | PIC24FJ256DA210 Evaluation Board DM240312 and DV164039 | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - Embedded - MCU, DSP | |
| Manufacturer | Microchip Technology | |
| Series | PIC® | |
| Part Status | Active | |
| Board Type | Evaluation Platform | |
| Type | MCU 16-Bit | |
| Core Processor | PIC | |
| Operating System | - | |
| Platform | PIC24FJ256DA210 Development Kit | |
| For Use With/Related Products | PIC24FJ256DA210 | |
| Mounting Type | Fixed | |
| Contents | Board(s), Cable(s), LCD, Power Supply, MPLAB® ICD 3 Programmer | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DV164039 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DV164039 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of DV164039 is new and unused, you can buy DV164039 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DV164039.
