| Manufacturer Part Number: | DRV8412DDWR |
|---|---|
| Manufacturer: | Texas Instruments |
| Product Category: | PMIC - Full, Half-Bridge Drivers |
| Available Quantity: | 14136 Pieces |
| Unit Price: | Quote by Email |
| Description: | IC BRIDGE DRIVER PAR 44HTSSOP |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DRV8412DDWR Datasheet |
| Internal Part Number | 898-DRV8412DDWR | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Manufacturer Product Page | DRV8412DDWR Specifications | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Online Catalog | Full, Half-Bridge Drivers | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Full, Half-Bridge Drivers | |
| Manufacturer | Texas Instruments | |
| Series | - | |
| Packaging | Digi-Reel® | |
| Part Status | Active | |
| Output Configuration | Half Bridge (4) | |
| Applications | DC Motors, Stepper Motors | |
| Interface | PWM | |
| Load Type | Inductive | |
| Technology | Power MOSFET | |
| Rds On (Typ) | 110 mOhm LS, 110 mOhm HS | |
| Current - Output / Channel | 3A | |
| Current - Peak Output | 6A | |
| Voltage - Supply | 10.8 V ~ 13.2 V | |
| Voltage - Load | 0 V ~ 52.5 V | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Features | Status Flag | |
| Fault Protection | Current Limiting, Over Temperature, Short Circuit, UVLO | |
| Mounting Type | Surface Mount | |
| Package / Case | 44-TSSOP (0.244", 6.20mm Width) Exposed Pad | |
| Supplier Device Package | 44-HTSSOP | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DRV8412DDWR | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DRV8412DDWR is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of DRV8412DDWR is new and unused, you can buy DRV8412DDWR Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DRV8412DDWR.
