Manufacturer Part Number: | DR2260A20U |
---|---|
Manufacturer: | Crydom Co. |
Product Category: | Solid State Relays |
Available Quantity: | 9030 Pieces |
Unit Price: | Quote by Email |
Description: | Solid State Relay SPST-NO (1 Form A) SSR with Integrated Heat Sink |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | DR2260A20U Datasheet |
Internal Part Number | 898-DR2260A20U | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Featured Product | Nova22 Din Rail Solid State Relays | |
3D Model | DR22.stp DR22.sat DR22.dwg | |
Online Catalog | DR22 Series | |
Category | Relays | |
Family | Solid State Relays | |
Manufacturer | Crydom Co. | |
Series | DR22 | |
Packaging | Bulk | |
Part Status | Active | |
Circuit | SPST-NO (1 Form A) | |
Output Type | AC, Zero Cross | |
On-State Resistance (Max) | - | |
Load Current | 20A | |
Voltage - Input | 90 ~ 280VAC/DC | |
Voltage - Load | 48 ~ 600 V | |
Mounting Type | DIN Rail | |
Termination Style | Screw Terminal | |
Package / Case | SSR with Integrated Heat Sink | |
Supplier Device Package | - | |
Relay Type | Relay | |
Standard Package | 20 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | DR2260A20U | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
DR2260A20U is in stock for immediate shipping now. We are the distributor of Crydom Co. all series components. The condition of DR2260A20U is new and unused, you can buy DR2260A20U Crydom Co. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DR2260A20U.
