| Manufacturer Part Number: | DPX2012LL85R2455A |
|---|---|
| Manufacturer: | Yageo |
| Product Category: | RF Diplexers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | RF Diplexor 2.4GHz ~ 2.5GHz / 4.9GHz ~ 5.95GHz 0805 (2012 Metric) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DPX2012LL85R2455A Datasheet |
| Internal Part Number | 898-DPX2012LL85R2455A | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Wireless Components | |
| Design Resources | IoT Product Selector | |
| Online Catalog | 2012 Series | |
| Category | RF/IF and RFID | |
| Family | RF Diplexers | |
| Manufacturer | Yageo | |
| Series | DPX | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Frequency Bands (Low / High) | 2.4GHz ~ 2.5GHz / 4.9GHz ~ 5.95GHz | |
| Low Band Attenuation (min / max dB) | 20.00dB / - | |
| High Band Attenuation (min / max dB) | 20.00dB / - | |
| Return Loss (Low Band / High Band) | 9.5dB / 9.5dB | |
| Mounting Type | Surface Mount | |
| Package / Case | 0805 (2012 Metric) | |
| Standard Package | 4,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DPX2012LL85R2455A | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DPX2012LL85R2455A is in stock for immediate shipping now. We are the distributor of Yageo all series components. The condition of DPX2012LL85R2455A is new and unused, you can buy DPX2012LL85R2455A Yageo with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DPX2012LL85R2455A.
