| Manufacturer Part Number: | DM330023 |
|---|---|
| Manufacturer: | Microchip Technology |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | dsPIC33F dsPICDEM™ Series Power Management, Motor Control Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DM330023 Datasheet |
| Internal Part Number | 898-DM330023 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Tuning Guide Application Note AN1292 Sensorless FOC Application Note AN1292 | |
| Video File | DigiKey’s 2015 Holiday Gift Guide – Another Geek Moment | |
| Design Resources | DM330023 BOM Development Tool Selector | |
| Reference Design Library | DM330023: Sensorless Speed Control w/PFC, 90~265AC | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Microchip Technology | |
| Series | dsPICDEM™ | |
| Part Status | Obsolete | |
| Main Purpose | Power Management, Motor Control | |
| Embedded | Yes, Other | |
| Utilized IC / Part | dsPIC33F | |
| Primary Attributes | AC Induction (ACIM) Motors, Brushless DC (BLDC) Motors, Permanent Magnet Synchronous (PMSM) Motors | |
| Secondary Attributes | Power Factor Corrected (PFC) | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DM330023 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DM330023 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of DM330023 is new and unused, you can buy DM330023 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DM330023.
