| Manufacturer Part Number: | DM1B-DSF-PEJ(22) |
|---|---|
| Manufacturer: | Hirose Electric Co Ltd |
| Product Category: | Memory Connectors - PC Card Sockets |
| Available Quantity: | 12160 Pieces |
| Unit Price: | Quote by Email |
| Description: | 12 (9 + 3) Position Card Connector Secure Digital - SD Surface Mount, Right Angle Gold |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DM1B-DSF-PEJ(22) Datasheet |
| Internal Part Number | 898-DM1B-DSF-PEJ(22) | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | DM1 Series | |
| Category | Connectors, Interconnects | |
| Family | Memory Connectors - PC Card Sockets | |
| Manufacturer | Hirose Electric Co Ltd | |
| Series | DM1 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Card Type | Secure Digital - SD | |
| Number of Positions | 12 (9 + 3) | |
| Connector Type | Connector and Ejector | |
| Insertion, Removal Method | Push In, Push Out | |
| Ejector Side | - | |
| Mounting Type | Surface Mount, Right Angle | |
| Features | Board Guide | |
| Height Above Board | 0.114" (2.90mm) | |
| Mounting Feature | Reverse - Bottom | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Standard Package | 450 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DM1B-DSF-PEJ(22) | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DM1B-DSF-PEJ(22) is in stock for immediate shipping now. We are the distributor of Hirose Electric Co Ltd all series components. The condition of DM1B-DSF-PEJ(22) is new and unused, you can buy DM1B-DSF-PEJ(22) Hirose Electric Co Ltd with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DM1B-DSF-PEJ(22).
