| Manufacturer Part Number: | DLW21SN181SQ2L |
|---|---|
| Manufacturer: | Murata Electronics North America |
| Product Category: | Common Mode Chokes |
| Available Quantity: | 21010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 2 Line Common Mode Choke Surface Mount 180 Ohm @ 100MHz 330mA DCR 350 mOhm |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DLW21SN181SQ2L Datasheet |
| Internal Part Number | 898-DLW21SN181SQ2L | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Common Mode Chokes | |
| Featured Product | Common Mode Choke Coils | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Online Catalog | EMIFIL® DLW21S Series | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Manufacturer | Murata Electronics North America | |
| Series | DLW21 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Filter Type | Signal Line | |
| Number of Lines | 2 | |
| Impedance @ Frequency | 180 Ohm @ 100MHz | |
| Inductance @ Frequency | - | |
| Current Rating (Max) | 330mA | |
| DC Resistance (DCR) (Max) | 350 mOhm | |
| Voltage Rating - DC | 50V | |
| Voltage Rating - AC | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Ratings | - | |
| Approvals | - | |
| Features | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.079" L x 0.047" W (2.00mm x 1.20mm) | |
| Height (Max) | 0.055" (1.40mm) | |
| Package / Case | Horizontal, 4 PC Pad | |
| Standard Package | 2,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DLW21SN181SQ2L | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DLW21SN181SQ2L is in stock for immediate shipping now. We are the distributor of Murata Electronics North America all series components. The condition of DLW21SN181SQ2L is new and unused, you can buy DLW21SN181SQ2L Murata Electronics North America with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DLW21SN181SQ2L.
