Manufacturer Part Number: | DK-57TS-LPC2478 |
---|---|
Manufacturer: | Future Designs Inc. |
Product Category: | Evaluation Boards - Sensors |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | LPC2478 ARM7 - Touch Screen Sensor Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | DK-57TS-LPC2478 Datasheet |
Internal Part Number | 898-DK-57TS-LPC2478 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | Development Tool Selector | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - Sensors | |
Manufacturer | Future Designs Inc. | |
Series | - | |
Part Status | Obsolete | |
Sensor Type | Touch Screen | |
Sensing Range | - | |
Interface | I²C | |
Sensitivity | - | |
Voltage - Supply | 5V | |
Embedded | Yes, MCU, 16/32-Bit | |
Supplied Contents | Board, Cables, LCD, Power Supply | |
Utilized IC / Part | LPC2478 ARM7 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | DK-57TS-LPC2478 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
DK-57TS-LPC2478 is in stock for immediate shipping now. We are the distributor of Future Designs Inc. all series components. The condition of DK-57TS-LPC2478 is new and unused, you can buy DK-57TS-LPC2478 Future Designs Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DK-57TS-LPC2478.
