Manufacturer Part Number: | DJ-503 |
---|---|
Manufacturer: | Amgis, LLC |
Product Category: | Arrays, Signal Transformers |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Unshielded 2 Coil Inductor Array 100µH Inductance - Connected in Series 25µH Inductance - Connected in Parallel 13 mOhm Max DC Resistance (DCR) - Parallel 6A Radial |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | DJ-503 Datasheet |
Internal Part Number | 898-DJ-503 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Category | Inductors, Coils, Chokes | |
Family | Arrays, Signal Transformers | |
Manufacturer | Amgis, LLC | |
Series | DJ | |
Packaging | Tray | |
Part Status | Active | |
Number of Coils | 2 | |
Inductance - Connected In Series | 100µH | |
Inductance - Connected In Parallel | 25µH | |
Tolerance | ±15% | |
Current Rating - Parallel | 6A | |
Current Rating - Series | 3A | |
Current Saturation - Parallel | - | |
Current Saturation - Series | - | |
DC Resistance (DCR) - Parallel | 13 mOhm Max | |
DC Resistance (DCR) - Series | 52 mOhm Max | |
Shielding | Unshielded | |
Operating Temperature | -40°C ~ 125°C | |
Mounting Type | Through Hole | |
Package / Case | Radial | |
Size / Dimension | 1.043" L x 0.531" W (26.50mm x 13.50mm) | |
Height | 1.161" (29.50mm) | |
Standard Package | 64 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | DJ-503 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
DJ-503 is in stock for immediate shipping now. We are the distributor of Amgis, LLC all series components. The condition of DJ-503 is new and unused, you can buy DJ-503 Amgis, LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DJ-503.
