Manufacturer Part Number: | DF38004H10WV |
---|---|
Manufacturer: | Renesas Electronics America |
Product Category: | Embedded - Microcontrollers |
Available Quantity: | 9178 Pieces |
Unit Price: | Quote by Email |
Description: | H8/300L H8® H8/300L SLP Microcontroller IC 8-Bit 10MHz 32KB (32K x 8) FLASH 64-QFP (14x14) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | DF38004H10WV Datasheet |
Internal Part Number | 898-DF38004H10WV | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Electromagnetic Noise Reduction Techniques Part 1 Digital to Analog Converter Part 1 Digital to Analog Converter Part 2 | |
RoHS Information | RoHS Compliance | |
Design Resources | Development Tool Selector | |
Category | Integrated Circuits (ICs) | |
Family | Embedded - Microcontrollers | |
Manufacturer | Renesas Electronics America | |
Series | H8® H8/300L SLP | |
Packaging | Tray | |
Part Status | Active | |
Core Processor | H8/300L | |
Core Size | 8-Bit | |
Speed | 10MHz | |
Connectivity | SCI | |
Peripherals | LCD, PWM, WDT | |
Number of I/O | 39 | |
Program Memory Size | 32KB (32K x 8) | |
Program Memory Type | FLASH | |
EEPROM Size | - | |
RAM Size | 1K x 8 | |
Voltage - Supply (Vcc/Vdd) | 1.8 V ~ 5.5 V | |
Data Converters | A/D 4x10b | |
Oscillator Type | Internal | |
Operating Temperature | -40°C ~ 85°C (TA) | |
Package / Case | 64-BQFP | |
Supplier Device Package | 64-QFP (14x14) | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | DF38004H10WV | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
DF38004H10WV is in stock for immediate shipping now. We are the distributor of Renesas Electronics America all series components. The condition of DF38004H10WV is new and unused, you can buy DF38004H10WV Renesas Electronics America with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DF38004H10WV.
