| Manufacturer Part Number: | DEMOBOARD TLE8201R |
|---|---|
| Manufacturer: | Infineon Technologies |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9013 Pieces |
| Unit Price: | Quote by Email |
| Description: | TLE8201 - Power Management, High and Low Side Driver (Internal FET) Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DEMOBOARD TLE8201R Datasheet |
| Internal Part Number | 898-DEMOBOARD TLE8201R | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Infineon Technologies | |
| Series | - | |
| Part Status | Obsolete | |
| Main Purpose | Power Management, High and Low Side Driver (Internal FET) | |
| Embedded | No | |
| Utilized IC / Part | TLE8201 | |
| Primary Attributes | 1 H-Bridge @ 3A, 4 Half Bridges- 2 @ 1A, 2 @ 0.5A, 5 High Side 1@ 2.5A, 4 @ 0.5A | |
| Secondary Attributes | SPI Interface, Intended for Automotive Door | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DEMOBOARD TLE8201R | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DEMOBOARD TLE8201R is in stock for immediate shipping now. We are the distributor of Infineon Technologies all series components. The condition of DEMOBOARD TLE8201R is new and unused, you can buy DEMOBOARD TLE8201R Infineon Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DEMOBOARD TLE8201R.
