Manufacturer Part Number: | DEA162450BT-1241A1 |
---|---|
Manufacturer: | TDK Corporation |
Product Category: | RF Filters |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | FILTER BANDPASS 2.45GHZ WLAN SMD |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | DEA162450BT-1241A1 Datasheet |
Internal Part Number | 898-DEA162450BT-1241A1 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
EDA / CAD Models | Download from Accelerated Designs | |
Online Catalog | DEA Series | |
Category | Filters | |
Family | RF Filters | |
Manufacturer | TDK Corporation | |
Series | DEA | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Frequency | 2.45GHz Center | |
Bandwidth | 100MHz | |
Filter Type | Band Pass | |
Ripple | - | |
Insertion Loss | 2dB | |
Package / Case | 0603 (1608 Metric), 4 PC Pad | |
Mounting Type | Surface Mount | |
Height (Max) | 0.028" (0.70mm) | |
Size / Dimension | 0.063" L x 0.031" W (1.60mm x 0.80mm) | |
Standard Package | 4,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | DEA162450BT-1241A1 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
DEA162450BT-1241A1 is in stock for immediate shipping now. We are the distributor of TDK Corporation all series components. The condition of DEA162450BT-1241A1 is new and unused, you can buy DEA162450BT-1241A1 TDK Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DEA162450BT-1241A1.
