Manufacturer Part Number: | DC749A |
---|---|
Manufacturer: | Linear Technology |
Product Category: | Evaluation Boards - LED Drivers |
Available Quantity: | 9012 Pieces |
Unit Price: | Quote by Email |
Description: | LTC3206 11, Non-Isolated Output LED Driver Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | DC749A Datasheet |
Internal Part Number | 898-DC749A | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Software Download | QuikEval System | |
Design Resources | DC749A Design File DC749A Schematic Development Tool Selector Lighting Product Selector | |
Online Catalog | LTC3206 Evaluation Board | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - LED Drivers | |
Manufacturer | Linear Technology | |
Series | - | |
Part Status | Active | |
Current - Output / Channel | - | |
Outputs and Type | 11, Non-Isolated | |
Voltage - Output | - | |
Features | Dimmable, I²C Interface | |
Voltage - Input | 2.7 V ~ 4.5 V | |
Supplied Contents | Board | |
Utilized IC / Part | LTC3206 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | DC749A | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
DC749A is in stock for immediate shipping now. We are the distributor of Linear Technology all series components. The condition of DC749A is new and unused, you can buy DC749A Linear Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DC749A.
