| Manufacturer Part Number: | DC2113A |
|---|---|
| Manufacturer: | Linear Technology |
| Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
| Available Quantity: | 9015 Pieces |
| Unit Price: | Quote by Email |
| Description: | LTC3649 - DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board |
| Lead Free Status / RoHS Status: | Not applicable / Not applicable |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DC2113A Datasheet |
| Internal Part Number | 898-DC2113A | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Video File | LTC3649 60V, 4A Monolithic Buck Regulator w/Rail-to-Rail Programmable Output and Integrated Current Monitoring | |
| Software Download | LTspice IV for Windows LTspice IV for Mac OS X 10.7+ LTC3649 Demo Circuit 1 LTC3649 Demo Circuit 2 | |
| Design Resources | DC2113A Design Files DC2113A Schematic | |
| Online Catalog | LTC3649 Demonstration Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
| Manufacturer | Linear Technology | |
| Series | - | |
| Part Status | Active | |
| Main Purpose | DC/DC, Step Down | |
| Outputs and Type | 1, Non-Isolated | |
| Power - Output | - | |
| Voltage - Output | 3.3V or 5V | |
| Current - Output | 4A | |
| Voltage - Input | 4 V ~ 60 V | |
| Regulator Topology | Buck | |
| Frequency - Switching | 500kHz | |
| Board Type | Fully Populated | |
| Supplied Contents | Board | |
| Utilized IC / Part | LTC3649 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DC2113A | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DC2113A is in stock for immediate shipping now. We are the distributor of Linear Technology all series components. The condition of DC2113A is new and unused, you can buy DC2113A Linear Technology with us at a very low price and quick delivery.
