| Manufacturer Part Number: | DC1948A |
|---|---|
| Manufacturer: | Linear Technology |
| Product Category: | Evaluation Boards - Linear Voltage Regulators |
| Available Quantity: | 9012 Pieces |
| Unit Price: | Quote by Email |
| Description: | LT3090 1 - Single Channels per IC Negative Adjustable Linear Voltage Regulator Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DC1948A Datasheet |
| Internal Part Number | 898-DC1948A | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Software Download | LTspice IV for Windows LTspice IV for Mac OS X 10.7+ LT3090 Demo Circuit | |
| Design Resources | DC1948A Design File DC1948A Schematic Development Tool Selector | |
| Online Catalog | LT3090 Demonstration Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - Linear Voltage Regulators | |
| Manufacturer | Linear Technology | |
| Series | - | |
| Part Status | Active | |
| Channels per IC | 1 - Single | |
| Voltage - Output | -1.25V, -2.5V, -5V, -12V or -15V | |
| Current - Output | 600mA | |
| Voltage - Input | -1.5 V ~ -36 V | |
| Regulator Type | Negative Adjustable | |
| Operating Temperature | -40°C ~ 125°C | |
| Board Type | Fully Populated | |
| Supplied Contents | Board | |
| Utilized IC / Part | LT3090 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DC1948A | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DC1948A is in stock for immediate shipping now. We are the distributor of Linear Technology all series components. The condition of DC1948A is new and unused, you can buy DC1948A Linear Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DC1948A.
