| Manufacturer Part Number: | DC1900A |
|---|---|
| Manufacturer: | Linear Technology |
| Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
| Available Quantity: | 9026 Pieces |
| Unit Price: | Quote by Email |
| Description: | LTM4644 µModule® DC/DC, Step Down 4, Non-Isolated Outputs Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DC1900A Datasheet |
| Internal Part Number | 898-DC1900A | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Software Download | LTspice IV for Windows LTspice IV for Mac OS X 10.7+ | |
| Design Resources | Development Tool Selector | |
| Featured Product | LTM4644 Quad DC/DC μModule Regulator | |
| Online Catalog | LTM4644 Demo Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
| Manufacturer | Linear Technology | |
| Series | µModule® | |
| Part Status | Active | |
| Main Purpose | DC/DC, Step Down | |
| Outputs and Type | 4, Non-Isolated | |
| Power - Output | - | |
| Voltage - Output | 1.2V, 1.5V, 2.5V, 3.3V | |
| Current - Output | 4A, 4A, 4A, 4A | |
| Voltage - Input | 4 V ~ 14 V | |
| Regulator Topology | Buck | |
| Frequency - Switching | 1MHz | |
| Board Type | Fully Populated | |
| Supplied Contents | Board | |
| Utilized IC / Part | LTM4644 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DC1900A | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DC1900A is in stock for immediate shipping now. We are the distributor of Linear Technology all series components. The condition of DC1900A is new and unused, you can buy DC1900A Linear Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DC1900A.
