Manufacturer Part Number: | DC1825A |
---|---|
Manufacturer: | Linear Technology |
Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
Available Quantity: | 9020 Pieces |
Unit Price: | Quote by Email |
Description: | LT8300 - DC/DC, Step Down 1, Isolated Outputs Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | DC1825A Datasheet |
Internal Part Number | 898-DC1825A | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Software Download | LTspice IV for Windows LTspice IV for Mac OS X 10.7+ LT8300 Demo Circuit | |
Design Resources | DC1825A Design Files DC1825A Schematic Development Tool Selector | |
Reference Design Library | DC1825A: 5V @ 250mA, 22 ~ 75V in, Buck | |
Online Catalog | LT8300 Demonstration Board | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
Manufacturer | Linear Technology | |
Series | - | |
Part Status | Active | |
Main Purpose | DC/DC, Step Down | |
Outputs and Type | 1, Isolated | |
Power - Output | - | |
Voltage - Output | 5V | |
Current - Output | 250mA | |
Voltage - Input | 22 V ~ 75 V | |
Regulator Topology | Flyback | |
Frequency - Switching | 330kHz | |
Board Type | Fully Populated | |
Supplied Contents | Board | |
Utilized IC / Part | LT8300 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | DC1825A | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
