Manufacturer Part Number: | DC1817B |
---|---|
Manufacturer: | Linear Technology |
Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
Available Quantity: | 9013 Pieces |
Unit Price: | Quote by Email |
Description: | LT3798 - AC/DC, Primary Side and PFC 1, Isolated Outputs Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | DC1817B Datasheet |
Internal Part Number | 898-DC1817B | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Software Download | LTspice IV for Windows LTspice IV for Mac OS X 10.7+ LT3798 Demo Circuit | |
Design Resources | DC1817 Design Files DC1817 Schematic Development Tool Selector | |
Reference Design Library | DC1817B: 24V @ 2A, 90 ~ 265VAC in | |
Online Catalog | LT3798 Demonstration Board | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
Manufacturer | Linear Technology | |
Series | - | |
Part Status | Active | |
Main Purpose | AC/DC, Primary Side and PFC | |
Outputs and Type | 1, Isolated | |
Power - Output | - | |
Voltage - Output | 24V | |
Current - Output | 2A | |
Voltage - Input | 90 ~ 265 VAC | |
Regulator Topology | Flyback | |
Frequency - Switching | - | |
Board Type | Fully Populated | |
Supplied Contents | Board | |
Utilized IC / Part | LT3798 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | DC1817B | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
DC1817B is in stock for immediate shipping now. We are the distributor of Linear Technology all series components. The condition of DC1817B is new and unused, you can buy DC1817B Linear Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DC1817B.
