Manufacturer Part Number: | DC1723A |
---|---|
Manufacturer: | Linear Technology |
Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
Available Quantity: | 9011 Pieces |
Unit Price: | Quote by Email |
Description: | LTM8050 µModule® DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | DC1723A Datasheet |
Internal Part Number | 898-DC1723A | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Video File | LTM8050 TECHCLIP - INVERTING (NEGATIVE) OUTPUT LTM8050 TechClip - Current Sharing and Load Transient Performance | |
Software Download | LTM8050 LTspice IV for Windows LTspice IV for Mac OS X 10.7+ | |
Design Resources | DC1723A Schematic DC1723A Design Files Development Tool Selector | |
Online Catalog | LTM8050 Demo Board | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
Manufacturer | Linear Technology | |
Series | µModule® | |
Part Status | Active | |
Main Purpose | DC/DC, Step Down | |
Outputs and Type | 1, Non-Isolated | |
Power - Output | - | |
Voltage - Output | 5V | |
Current - Output | 2A | |
Voltage - Input | 7.5 V ~ 58 V | |
Regulator Topology | Buck | |
Frequency - Switching | 400kHz | |
Board Type | Fully Populated | |
Supplied Contents | Board | |
Utilized IC / Part | LTM8050 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | DC1723A | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
DC1723A is in stock for immediate shipping now. We are the distributor of Linear Technology all series components. The condition of DC1723A is new and unused, you can buy DC1723A Linear Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DC1723A.
