| Manufacturer Part Number: | DC1666A |
|---|---|
| Manufacturer: | Linear Technology |
| Product Category: | Evaluation Boards - LED Drivers |
| Available Quantity: | 9038 Pieces |
| Unit Price: | Quote by Email |
| Description: | LT3791 1, Non-Isolated Output LED Driver Evaluation Board |
| Lead Free Status / RoHS Status: | Not applicable / Not applicable |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DC1666A Datasheet |
| Internal Part Number | 898-DC1666A | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Software Download | LTspice IV for Windows LTspice IV for Mac OS X 10.7+ | |
| Design Resources | DC1666A Design Files DC1666A Schematic Development Tool Selector Lighting Product Selector | |
| Featured Product | LT3791 LED Driver Controller | |
| Reference Design Library | DC1666A: 8 LEDs @ 2A, 4.7 ~ 60V in | |
| Online Catalog | LT3791 Evaluation Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - LED Drivers | |
| Manufacturer | Linear Technology | |
| Series | - | |
| Part Status | Active | |
| Current - Output / Channel | 2A | |
| Outputs and Type | 1, Non-Isolated | |
| Voltage - Output | 9.5 V ~ 25.5 V | |
| Features | Dimmable | |
| Voltage - Input | 4.7 V ~ 60 V | |
| Supplied Contents | Board | |
| Utilized IC / Part | LT3791 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DC1666A | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DC1666A is in stock for immediate shipping now. We are the distributor of Linear Technology all series components. The condition of DC1666A is new and unused, you can buy DC1666A Linear Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DC1666A.
