| Manufacturer Part Number: | DC1568A |
|---|---|
| Manufacturer: | Linear Technology |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9040 Pieces |
| Unit Price: | Quote by Email |
| Description: | LT3652 - Power Management, Battery Charger Evaluation Board |
| Lead Free Status / RoHS Status: | Not applicable / Not applicable |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DC1568A Datasheet |
| Internal Part Number | 898-DC1568A | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Power-Tracking Batt-Charger Article Designing a Solar Cell Battery Charger | |
| Product Training Modules | LT3652 Multi-Chemistry Battery Charger for Solar Power | |
| Video File | Linear Technology LT3652 | |
| Design Resources | DC1568A Design Files DC1568A Schematic Development Tool Selector | |
| Featured Product | Energy Harvesting Power Products | |
| Reference Design Library | DC1568A(#1):2 Cell, 8.2V, 2A Max, Solar DC1568A(#2):2 Cell, 8.2V, 2A Max, Solar | |
| Online Catalog | LT3652 Demonstration Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Linear Technology | |
| Series | - | |
| Part Status | Active | |
| Main Purpose | Power Management, Battery Charger | |
| Embedded | No | |
| Utilized IC / Part | LT3652 | |
| Primary Attributes | Multi-Chemistry, Solar Power | |
| Secondary Attributes | LED Status Indicators | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DC1568A | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DC1568A is in stock for immediate shipping now. We are the distributor of Linear Technology all series components. The condition of DC1568A is new and unused, you can buy DC1568A Linear Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DC1568A.
