| Manufacturer Part Number: | DC1533A |
|---|---|
| Manufacturer: | Linear Technology |
| Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
| Available Quantity: | 9011 Pieces |
| Unit Price: | Quote by Email |
| Description: | LTM8045 µModule® DC/DC, Negative Inverter 1, Non-Isolated Outputs Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DC1533A Datasheet |
| Internal Part Number | 898-DC1533A | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Software Download | LTspice IV for Windows LTspice IV for Mac OS X 10.7+ | |
| Design Resources | DC1533A Schematic DC1533A Design Files Development Tool Selector | |
| Reference Design Library | DC1533A: -5V @ 700mA Inverting, 2.8 ~ 18V in | |
| Online Catalog | LTM8045 Demo Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
| Manufacturer | Linear Technology | |
| Series | µModule® | |
| Part Status | Active | |
| Main Purpose | DC/DC, Negative Inverter | |
| Outputs and Type | 1, Non-Isolated | |
| Power - Output | - | |
| Voltage - Output | -4.83 V ~ -5.19 V | |
| Current - Output | 700mA | |
| Voltage - Input | 2.8 V ~ 18 V | |
| Regulator Topology | Inverting | |
| Frequency - Switching | 700kHz | |
| Board Type | Fully Populated | |
| Supplied Contents | Board | |
| Utilized IC / Part | LTM8045 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DC1533A | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DC1533A is in stock for immediate shipping now. We are the distributor of Linear Technology all series components. The condition of DC1533A is new and unused, you can buy DC1533A Linear Technology with us at a very low price and quick delivery.
