Manufacturer Part Number: | DC1280A |
---|---|
Manufacturer: | Linear Technology |
Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
Available Quantity: | 9016 Pieces |
Unit Price: | Quote by Email |
Description: | LT3471 - DC/DC, Step Up 2, Non-Isolated Outputs Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | DC1280A Datasheet |
Internal Part Number | 898-DC1280A | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | DC1280A Design File DC1280A Schematic Development Tool Selector | |
Reference Design Library | DC1280A: +12V @ 0.3A, -12V @ 0.2A, 4.5 ~ 10V in | |
Online Catalog | LTC3471EDD Demonstration Board | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
Manufacturer | Linear Technology | |
Series | - | |
Part Status | Active | |
Main Purpose | DC/DC, Step Up | |
Outputs and Type | 2, Non-Isolated | |
Power - Output | - | |
Voltage - Output | 12V, -12V | |
Current - Output | 300mA, 200mA | |
Voltage - Input | 4.5 V ~ 10 V | |
Regulator Topology | Boost | |
Frequency - Switching | 1.2MHz | |
Board Type | Fully Populated | |
Supplied Contents | Board | |
Utilized IC / Part | LT3471 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | DC1280A | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
DC1280A is in stock for immediate shipping now. We are the distributor of Linear Technology all series components. The condition of DC1280A is new and unused, you can buy DC1280A Linear Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DC1280A.
