Manufacturer Part Number: | DC1028A |
---|---|
Manufacturer: | Linear Technology |
Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
Available Quantity: | 9014 Pieces |
Unit Price: | Quote by Email |
Description: | LT3513 - Special Purpose DC/DC, LCD Supply 5, Non-Isolated Outputs Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | DC1028A Datasheet |
Internal Part Number | 898-DC1028A | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Software Download | QuikEval System LTspice IV for Windows LTspice IV for Mac OS X 10.7+ LT3513 Demo Circuit | |
Design Resources | DC1028A Design File DC1028A Schematic Development Tool Selector | |
Online Catalog | LT3513EUHF Demonstration Board | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
Manufacturer | Linear Technology | |
Series | - | |
Part Status | Active | |
Main Purpose | Special Purpose DC/DC, LCD Supply | |
Outputs and Type | 5, Non-Isolated | |
Power - Output | - | |
Voltage - Output | 3.3V, 5V, 8V, 22V, -10V | |
Current - Output | 500mA, 500mA, 80mA, 20mA, 20mA | |
Voltage - Input | 8 V ~ 30 V | |
Regulator Topology | Buck | |
Frequency - Switching | 2MHz | |
Board Type | Fully Populated | |
Supplied Contents | Board | |
Utilized IC / Part | LT3513 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | DC1028A | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
DC1028A is in stock for immediate shipping now. We are the distributor of Linear Technology all series components. The condition of DC1028A is new and unused, you can buy DC1028A Linear Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DC1028A.
