Manufacturer Part Number: | DBMM-5W5P |
---|---|
Manufacturer: | ITT Cannon, LLC |
Product Category: | D-Sub, D-Shaped Connectors - Housings |
Available Quantity: | 9168 Pieces |
Unit Price: | Quote by Email |
Description: | Plug for Male Contacts Housing D-Sub, Combo Connector 5 (Coax or Power) Position |
Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
Moisture Sensitivity Level (MSL): | |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | DBMM-5W5P Datasheet |
Internal Part Number | 898-DBMM-5W5P | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Featured Product | D-Subminiature Connector Series | |
Online Catalog | MIL-DTL-24308, Combo D®, DMM Series | |
Category | Connectors, Interconnects | |
Family | D-Sub, D-Shaped Connectors - Housings | |
Manufacturer | ITT Cannon, LLC | |
Series | MIL-DTL-24308, Combo D®, D*MM | |
Packaging | Bulk | |
Part Status | Active | |
Connector Style | D-Sub, Combo | |
Connector Type | Plug for Male Contacts | |
Number of Positions | 5 (Coax or Power) | |
Number of Rows | 1 | |
Shell Size, Connector Layout | 3 (DB, B) - 5W5 | |
Contact Type | Coax or Power | |
Mounting Type | Free Hanging (In-Line) | |
Flange Feature | Housing/Shell (Unthreaded) | |
Features | Shielded | |
Shell Material, Finish | Steel, Yellow Chromate Plated Zinc | |
Shell Finish Thickness | - | |
Note | Contacts Not Provided | |
Ingress Protection | - | |
Operating Temperature | -55°C ~ 150°C | |
Mating Cycles | - | |
Dielectric Material | Polyester | |
Color | Black | |
Standard Package | 56 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | DBMM-5W5P | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
DBMM-5W5P is in stock for immediate shipping now. We are the distributor of ITT Cannon, LLC all series components. The condition of DBMM-5W5P is new and unused, you can buy DBMM-5W5P ITT Cannon, LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DBMM-5W5P.
