| Manufacturer Part Number: | DB5W5PA00LF |
|---|---|
| Manufacturer: | Amphenol FCI |
| Product Category: | D-Sub, D-Shaped Connectors - Housings |
| Available Quantity: | 9023 Pieces |
| Unit Price: | Quote by Email |
| Description: | Plug for Male Contacts Housing D-Sub, Combo Connector 5 (Power) Position |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DB5W5PA00LF Datasheet |
| Internal Part Number | 898-DB5W5PA00LF | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | D-Sub I/O Connectors | |
| 3D Model | DB5W5PAxx.igs DB5W5PAxx.prt DB5W5PAxx.stp | |
| Online Catalog | D Series | |
| Category | Connectors, Interconnects | |
| Family | D-Sub, D-Shaped Connectors - Housings | |
| Manufacturer | Amphenol FCI | |
| Series | DW | |
| Packaging | Bulk | |
| Part Status | Active | |
| Connector Style | D-Sub, Combo | |
| Connector Type | Plug for Male Contacts | |
| Number of Positions | 5 (Power) | |
| Number of Rows | 1 | |
| Shell Size, Connector Layout | 3 (DB, B) - 5W5 | |
| Contact Type | Power | |
| Mounting Type | Free Hanging (In-Line) | |
| Flange Feature | Housing/Shell (Unthreaded) | |
| Features | Grounding Indents | |
| Shell Material, Finish | Steel, Tin Plated | |
| Shell Finish Thickness | - | |
| Note | Contacts Not Provided | |
| Ingress Protection | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Mating Cycles | - | |
| Dielectric Material | Thermoplastic | |
| Color | - | |
| Standard Package | 20 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DB5W5PA00LF | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DB5W5PA00LF is in stock for immediate shipping now. We are the distributor of Amphenol FCI all series components. The condition of DB5W5PA00LF is new and unused, you can buy DB5W5PA00LF Amphenol FCI with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DB5W5PA00LF.
