| Manufacturer Part Number: | DA12-120US-M |
|---|---|
| Manufacturer: | Artesyn Embedded Technologies |
| Product Category: | AC DC Desktop, Wall Adapters |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 12V 12W AC/DC External Wall Mount Adapter Fixed Blade Input |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DA12-120US-M Datasheet |
| Internal Part Number | 898-DA12-120US-M | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | Declaration of Conformity | |
| Featured Product | DA12-M Switching Wall-Mount AC-DC Power Supplies | |
| 3D Model | DA12yyyUS-M.stp | |
| PCN Packaging | CSA Marking 20/Sep/2013 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Desktop, Wall Adapters | |
| Manufacturer | Artesyn Embedded Technologies | |
| Series | DA12-M | |
| Part Status | Obsolete | |
| Region Utilized | North America | |
| Form | Wall Mount | |
| Input Type | Fixed Blade | |
| Voltage - Input | 90 ~ 264 VAC | |
| Voltage - Output | 12V | |
| Current - Output (Max) | 1A | |
| Power (Watts) | 12W | |
| No Load Power Consumption | - | |
| Polarization | Positive Center | |
| Applications | ITE (Commercial), Medical | |
| Efficiency | Level V | |
| Operating Temperature | 0°C ~ 40°C | |
| Output Connector | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm | |
| Size / Dimension | 2.36" L x 1.10" W x 1.99" H (60.0mm x 28.0mm x 50.6mm) | |
| Approvals | CB, CE | |
| Power (Watts) - Max | 12W | |
| Input Connector | NEMA 1-15P | |
| Cord Length | 59" (1.50m) | |
| Weight | 0.001 KG | |
| Standard Package | 200 | |
| Application | Email for details | |
| Replacement Part | DA12-120US-M | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DA12-120US-M is in stock for immediate shipping now. We are the distributor of Artesyn Embedded Technologies all series components. The condition of DA12-120US-M is new and unused, you can buy DA12-120US-M Artesyn Embedded Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DA12-120US-M.
