Manufacturer Part Number: | CXS3106A14S5P |
---|---|
Manufacturer: | Switchcraft Inc. |
Product Category: | Circular Connectors |
Available Quantity: | 9017 Pieces |
Unit Price: | Quote by Email |
Description: | 5 Position Circular Connector Plug, Male Pins Solder Silver |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | CXS3106A14S5P Datasheet |
Internal Part Number | 898-CXS3106A14S5P | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Online Catalog | MIL-E-QUAL® | |
Category | Connectors, Interconnects | |
Family | Circular Connectors | |
Manufacturer | Conxall/Switchcraft | |
Series | MIL-E-QUAL® | |
Packaging | Bulk | |
Part Status | Active | |
Connector Type | Plug, Male Pins | |
Number of Positions | 5 | |
Shell Size - Insert | 14S-5 | |
Shell Size, MIL | - | |
Mounting Type | Free Hanging (In-Line) | |
Termination | Solder | |
Fastening Type | Threaded | |
Orientation | Keyed | |
Ingress Protection | Weathertight | |
Shell Material, Finish | Nylon | |
Contact Finish | Silver | |
Features | Cable Clamp | |
Contact Finish Thickness | - | |
Current Rating | - | |
Voltage - Rated | 500V | |
Operating Temperature | -40°C ~ 125°C | |
Standard Package | 25 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | CXS3106A14S5P | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
CXS3106A14S5P is in stock for immediate shipping now. We are the distributor of Switchcraft Inc. all series components. The condition of CXS3106A14S5P is new and unused, you can buy CXS3106A14S5P Switchcraft Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CXS3106A14S5P.
