| Manufacturer Part Number: | CW160808-2N2D |
|---|---|
| Manufacturer: | Bourns Inc. |
| Product Category: | Fixed Inductors |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 2.2nH Unshielded Wirewound Inductor 700mA 80 mOhm 0603 (1608 Metric) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | CW160808-2N2D Datasheet |
| Internal Part Number | 898-CW160808-2N2D | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | CW160808 Series Material Declaration | |
| 3D Model | CW160808.stp | |
| PCN Assembly/Origin | Magnetic products Oct/2013 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Manufacturer | Bourns Inc. | |
| Series | CW160808 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Type | Wirewound | |
| Material - Core | Alumina | |
| Inductance | 2.2nH | |
| Tolerance | ±15% | |
| Current Rating | 700mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 80 mOhm | |
| Q @ Freq | 16 @ 250MHz | |
| Frequency - Self Resonant | 6GHz | |
| Ratings | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Frequency - Test | 250MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 0603 (1608 Metric) | |
| Size / Dimension | 0.065" L x 0.041" W (1.65mm x 1.05mm) | |
| Height - Seated (Max) | 0.047" (1.20mm) | |
| Standard Package | 3,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | CW160808-2N2D | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
CW160808-2N2D is in stock for immediate shipping now. We are the distributor of Bourns Inc. all series components. The condition of CW160808-2N2D is new and unused, you can buy CW160808-2N2D Bourns Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CW160808-2N2D.
