| Manufacturer Part Number: | CSNX25 |
|---|---|
| Manufacturer: | Honeywell Sensing and Productivity Solutions |
| Product Category: | Current Transducers |
| Available Quantity: | 9326 Pieces |
| Unit Price: | Quote by Email |
| Description: | Current Sensor 56A 1 Channel Magnetoresistive, Open Loop Bidirectional Module, Single Pass Through |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | CSNX25 Datasheet |
| Internal Part Number | 898-CSNX25 | |
| Manufacturer Lead time | 6-8 weeks | |
| 지위 | New & Unused, Original Sealed | |
| Online Catalog | CSN Series | |
| Category | Sensors, Transducers | |
| Family | Current Transducers | |
| Manufacturer | Honeywell Sensing and Productivity Solutions | |
| Series | CSN | |
| Packaging | Bulk | |
| Part Status | Active | |
| For Measuring | AC/DC | |
| Sensor Type | Magnetoresistive, Open Loop | |
| Current - Sensing | 56A | |
| Number of Channels | 1 | |
| Output | Ratiometric, Current | |
| Sensitivity | - | |
| Frequency | - | |
| Linearity | - | |
| Accuracy | ±0.24% | |
| Voltage - Supply | 4.75 V ~ 5.25 V | |
| Response Time | 0.2µs | |
| Current - Supply (Max) | 12mA | |
| Operating Temperature | -40°C ~ 85°C | |
| Polarization | Bidirectional | |
| Mounting Type | Through Hole | |
| Package / Case | Module, Single Pass Through | |
| Standard Package | 40 | |
| 무게 | 0.001 KG | |
| 신청 | Email for details | |
| Replacement Part | CSNX25 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
CSNX25 is in stock for immediate shipping now. We are the distributor of Honeywell Sensing and Productivity Solutions all series components. The condition of CSNX25 is new and unused, you can buy CSNX25 Honeywell Sensing and Productivity Solutions with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CSNX25.
