| Manufacturer Part Number: | CSD87351Q5D |
|---|---|
| Manufacturer: | Texas Instruments |
| Product Category: | Transistors - FETs, MOSFETs - Arrays |
| Available Quantity: | 11510 Pieces |
| Unit Price: | Quote by Email |
| Description: | MOSFET 2N-CH 30V 32A 8LSON |
| Lead Free Status / RoHS Status: | Contains lead / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | CSD87351Q5D Datasheet |
| Internal Part Number | 898-CSD87351Q5D | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | NexFET MOSFET Technology | |
| Video File | PowerStack™ Packaging Technology Overview | |
| PCN Design/Specification | Qualification Revision A 01/Jul/2014 | |
| PCN Assembly/Origin | Qualification Wire Bond 27/May/2014 Assembly/Test Site Addition 10/Aug/2015 | |
| PCN Packaging | MSL1 Bubble Bag Conversion 24/Sep/2013 | |
| Manufacturer Product Page | CSD87351Q5D Specifications | |
| Online Catalog | N-Channel Logic Level Gate FETs | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - FETs, MOSFETs - Arrays | |
| Manufacturer | Texas Instruments | |
| Series | NexFET™ | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| FET Type | 2 N-Channel (Dual) | |
| FET Feature | Logic Level Gate | |
| Drain to Source Voltage (Vdss) | 30V | |
| Current - Continuous Drain (Id) @ 25°C | 32A | |
| Rds On (Max) @ Id, Vgs | 7.6 mOhm @ 20A, 8V | |
| Vgs(th) (Max) @ Id | 2.1V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 7.7nC @ 4.5V | |
| Input Capacitance (Ciss) @ Vds | 1255pF @ 15V | |
| Power - Max | 12W | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-PowerLDFN | |
| Supplier Device Package | 8-LSON (5x6) | |
| Standard Package | 2,500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | CSD87351Q5D | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
CSD87351Q5D is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of CSD87351Q5D is new and unused, you can buy CSD87351Q5D Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CSD87351Q5D.
