Manufacturer Part Number: | CSD75205W1015 |
---|---|
Manufacturer: | Texas Instruments |
Product Category: | Transistors - FETs, MOSFETs - Arrays |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | MOSFET 2P-CH 20V 1.2A 6DSBGA |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | CSD75205W1015 Datasheet |
Internal Part Number | 898-CSD75205W1015 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | NexFET MOSFET Technology | |
Video File | NexFET Power Block PowerStack™ Packaging Technology Overview | |
PCN Obsolescence/ EOL | Multiple Devices 20/Feb/2014 | |
Category | Discrete Semiconductor Products | |
Family | Transistors - FETs, MOSFETs - Arrays | |
Manufacturer | Texas Instruments | |
Series | NexFET™ | |
Packaging | Tape & Reel (TR) | |
Part Status | Obsolete | |
FET Type | 2 P-Channel (Dual) | |
FET Feature | Logic Level Gate | |
Drain to Source Voltage (Vdss) | 20V | |
Current - Continuous Drain (Id) @ 25°C | 1.2A | |
Rds On (Max) @ Id, Vgs | 120 mOhm @ 1A, 4.5V | |
Vgs(th) (Max) @ Id | 850mV @ 250µA | |
Gate Charge (Qg) @ Vgs | 2.2nC @ 4.5V | |
Input Capacitance (Ciss) @ Vds | 265pF @ 10V | |
Power - Max | 750mW | |
Operating Temperature | -55°C ~ 150°C (TJ) | |
Mounting Type | Surface Mount | |
Package / Case | 6-UFBGA, DSBGA | |
Supplier Device Package | 6-DSBGA (1x1.5) | |
Standard Package | 3,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | CSD75205W1015 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
CSD75205W1015 is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of CSD75205W1015 is new and unused, you can buy CSD75205W1015 Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CSD75205W1015.
