| Manufacturer Part Number: | CSD17309Q3 |
|---|---|
| Manufacturer: | Texas Instruments |
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | MOSFET N-CH 30V 60A 8SON |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | CSD17309Q3 Datasheet |
| Internal Part Number | 898-CSD17309Q3 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | NexFET MOSFET Technology | |
| Video File | NexFET Power Block PowerStack™ Packaging Technology Overview | |
| Featured Product | Create your power design now with TI’s WEBENCH® Designer | |
| PCN Design/Specification | Qualification Revision A 01/Jul/2014 | |
| PCN Assembly/Origin | Qualification Assembly/Test Site 03/Mar/2014 Qualification Wire Bond 27/May/2014 Assembly/Test Site Revision C 09/Feb/2015 | |
| Manufacturer Product Page | CSD17309Q3 Specifications | |
| Online Catalog | N-Channel Logic Level Gate FETs | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - FETs, MOSFETs - Single | |
| Manufacturer | Texas Instruments | |
| Series | NexFET™ | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Logic Level Gate | |
| Drain to Source Voltage (Vdss) | 30V | |
| Current - Continuous Drain (Id) @ 25°C | 20A (Ta), 60A (Tc) | |
| Rds On (Max) @ Id, Vgs | 5.4 mOhm @ 18A, 8V | |
| Vgs(th) (Max) @ Id | 1.7V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 10nC @ 4.5V | |
| Input Capacitance (Ciss) @ Vds | 1440pF @ 15V | |
| Power - Max | 2.8W | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-PowerTDFN | |
| Supplier Device Package | 8-VSON (3.3x3.3) | |
| Standard Package | 2,500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | CSD17309Q3 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
CSD17309Q3 is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of CSD17309Q3 is new and unused, you can buy CSD17309Q3 Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CSD17309Q3.
