| Manufacturer Part Number: | CSCA0500A000B15B01 |
|---|---|
| Manufacturer: | Honeywell Sensing and Productivity Solutions |
| Product Category: | Current Transducers |
| Available Quantity: | 9019 Pieces |
| Unit Price: | Quote by Email |
| Description: | Current Sensor 500A 1 Channel Hall Effect, Open Loop Bidirectional Module |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | CSCA0500A000B15B01 Datasheet |
| Internal Part Number | 898-CSCA0500A000B15B01 | |
| Manufacturer Lead time | 6-8 weeks | |
| 지위 | New & Unused, Original Sealed | |
| PCN Design/Specification | CSCA-A Series Mating Connector 16/Feb/2013 | |
| Online Catalog | CSCA-A Series | |
| Category | Sensors, Transducers | |
| Family | Current Transducers | |
| Manufacturer | Honeywell Sensing and Productivity Solutions | |
| Series | CSCA-A | |
| Packaging | Bulk | |
| Part Status | Active | |
| For Measuring | AC/DC | |
| Sensor Type | Hall Effect, Open Loop | |
| Current - Sensing | 500A | |
| Number of Channels | 1 | |
| Output | Ratiometric, Voltage | |
| Sensitivity | - | |
| Frequency | DC ~ 50kHz | |
| Linearity | ±1% | |
| Accuracy | ±2% | |
| Voltage - Supply | 15V | |
| Response Time | 3µs | |
| Current - Supply (Max) | 17mA | |
| Operating Temperature | -10°C ~ 80°C | |
| Polarization | Bidirectional | |
| Mounting Type | Chassis Mount | |
| Package / Case | Module | |
| Standard Package | 10 | |
| 무게 | 0.001 KG | |
| 신청 | Email for details | |
| Replacement Part | CSCA0500A000B15B01 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
CSCA0500A000B15B01 is in stock for immediate shipping now. We are the distributor of Honeywell Sensing and Productivity Solutions all series components. The condition of CSCA0500A000B15B01 is new and unused, you can buy CSCA0500A000B15B01 Honeywell Sensing and Productivity Solutions with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CSCA0500A000B15B01.
