| Manufacturer Part Number: | CS2320-7R |
|---|---|
| Manufacturer: | Bel Power Solutions |
| Product Category: | DC DC Converters |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | DC/DC CONVERT DUAL 12V 4A |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | CS2320-7R Datasheet |
| Internal Part Number | 898-CS2320-7R | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Power Solutions and Protection | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | DC DC Converters | |
| Manufacturer | Bel Power Solutions | |
| Series | Melcher S | |
| Packaging | Bulk | |
| Part Status | Active | |
| Type | Isolated | |
| Voltage - Input | 28 ~ 140 V | |
| Output | 12V, 12V | |
| Number of Outputs | 2 | |
| Output - 1 @ Current (Max) | 12 VDC @ 4A | |
| Output - 2 @ Current (Max) | 12 VDC @ 4A | |
| Output - 3 @ Current (Max) | - | |
| Output - 4 @ Current (Max) | - | |
| Power (Watts) | 100W | |
| Applications | ITE (Commercial), Railway | |
| Mounting Type | Chassis Mount | |
| Operating Temperature | -25°C ~ 71°C | |
| Efficiency | 80% | |
| Package / Case | Module | |
| Size / Dimension | 6.73" L x 4.37" W x 2.06" H (171.0mm x 111.0mm x 52.2mm) | |
| Power (Watts) - Max | 96W | |
| Approvals | CE, CSA, EN, IEC, TUV, UL | |
| Standard Package | 5 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | CS2320-7R | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
CS2320-7R is in stock for immediate shipping now. We are the distributor of Bel Power Solutions all series components. The condition of CS2320-7R is new and unused, you can buy CS2320-7R Bel Power Solutions with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CS2320-7R.
