| Manufacturer Part Number: | CMS3-1-R |
|---|---|
| Manufacturer: | Eaton |
| Product Category: | Common Mode Chokes |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 28µH @ 100kHz 2 Line Common Mode Choke Surface Mount 5.7A DCR 5 mOhm (Typ) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | CMS3-1-R Datasheet |
| Internal Part Number | 898-CMS3-1-R | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Multiple Devices 31/Aug/2013 Coiltronics Magnetics Facility 31/Aug/2013 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Online Catalog | CMS Series | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Manufacturer | Eaton | |
| Series | CMS | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Filter Type | Power Line | |
| Number of Lines | 2 | |
| Impedance @ Frequency | - | |
| Inductance @ Frequency | 28µH @ 100kHz | |
| Current Rating (Max) | 5.7A | |
| DC Resistance (DCR) (Max) | 5 mOhm (Typ) | |
| Voltage Rating - DC | - | |
| Voltage Rating - AC | - | |
| Operating Temperature | -40°C ~ 160°C | |
| Ratings | - | |
| Approvals | - | |
| Features | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.550" L x 0.550" W (13.97mm x 13.97mm) | |
| Height (Max) | 0.236" (6.00mm) | |
| Package / Case | Horizontal, 4 PC Pad | |
| Standard Package | 600 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | CMS3-1-R | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
CMS3-1-R is in stock for immediate shipping now. We are the distributor of Eaton all series components. The condition of CMS3-1-R is new and unused, you can buy CMS3-1-R Eaton with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CMS3-1-R.
