Manufacturer Part Number: | CMDA5DR7D1Z |
---|---|
Manufacturer: | Visual Communications Company - VCC |
Product Category: | LED Indication - Discrete |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Red LED Indication - Discrete 1.7V 2-SMD, No Lead |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 4 (72 Hours) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | CMDA5DR7D1Z Datasheet |
Internal Part Number | 898-CMDA5DR7D1Z | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
PCN Obsolescence/ EOL | Multiple Devices 28/Feb/2014 | |
EDA / CAD Models | Download from Accelerated Designs | |
Category | Optoelectronics | |
Family | LED Indication - Discrete | |
Manufacturer | Visual Communications Company - VCC | |
Series | - | |
Packaging | Tape & Reel (TR) | |
Part Status | Obsolete | |
Color | Red | |
Lens Color | - | |
Lens Transparency | Diffused | |
Millicandela Rating | 11.7mcd | |
Lens Style/Size | Rectangle with Flat Top, 1.40mm x 1.25mm | |
Voltage - Forward (Vf) (Typ) | 1.7V | |
Current - Test | 20mA | |
Viewing Angle | 150° | |
Mounting Type | Surface Mount, Right Angle | |
Wavelength - Dominant | - | |
Wavelength - Peak | 660nm | |
Features | - | |
Package / Case | 2-SMD, No Lead | |
Supplier Device Package | SMD | |
Size / Dimension | 2.00mm L x 0.80mm W | |
Height (Max) | - | |
Standard Package | 4,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | CMDA5DR7D1Z | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
CMDA5DR7D1Z is in stock for immediate shipping now. We are the distributor of Visual Communications Company - VCC all series components. The condition of CMDA5DR7D1Z is new and unused, you can buy CMDA5DR7D1Z Visual Communications Company - VCC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CMDA5DR7D1Z.
