CM309A5.120MABJT

CM309A5.120MABJT
Manufacturer Part Number:CM309A5.120MABJT
Manufacturer:
Product Category:Crystals
Available Quantity:9010 Pieces
Unit Price:Quote by Email
Description:5.12MHz ±30ppm Crystal 18pF 150 Ohm -10°C ~ 60°C Surface Mount 2-SOJ, 2.85mm pitch
Lead Free Status / RoHS Status:Contains lead / RoHS non-compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):Obsolete / Discontinued
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: CM309A5.120MABJT Datasheet
CM309A5.120MABJT´s Parameters
Internal Part Number898-CM309A5.120MABJT
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
CategoryCrystals and Oscillators
FamilyCrystals
ManufacturerCitizen Finedevice Co Ltd
SeriesCM309A
PackagingCut Tape (CT)
Part StatusObsolete
TypeMHz Crystal
Frequency5.12MHz
Frequency Stability±50ppm
Frequency Tolerance±30ppm
Load Capacitance18pF
ESR (Equivalent Series Resistance)150 Ohm
Operating ModeFundamental
Operating Temperature-10°C ~ 60°C
Ratings-
Mounting TypeSurface Mount
Package / Case2-SOJ, 2.85mm pitch
Size / Dimension0.528" L x 0.200" W (13.40mm x 5.08mm)
Height0.181" (4.60mm)
Standard Package 1
Weight0.001 KG
ApplicationEmail for details
Replacement PartCM309A5.120MABJT
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

CM309A5.120MABJT is in stock for immediate shipping now. We are the distributor of Citizen Finedevice Co Ltd all series components. The condition of CM309A5.120MABJT is new and unused, you can buy CM309A5.120MABJT Citizen Finedevice Co Ltd with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for CM309A5.120MABJT.
