Manufacturer Part Number: | CF453215-1R8K |
---|---|
Manufacturer: | Bourns Inc. |
Product Category: | Fixed Inductors |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 1.8µH Shielded Multilayer Inductor 390mA 650 mOhm Max 1812 (4532 Metric) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | CF453215-1R8K Datasheet |
Internal Part Number | 898-CF453215-1R8K | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
RoHS Information | CF453215 Series Material Declaration | |
PCN Obsolescence/ EOL | CF252016,CF322513,Mar/2010 | |
EDA / CAD Models | Download from Accelerated Designs | |
Category | Inductors, Coils, Chokes | |
Family | Fixed Inductors | |
Manufacturer | Bourns Inc. | |
Series | CF453215 | |
Packaging | Tape & Reel (TR) | |
Part Status | Obsolete | |
Type | Multilayer | |
Material - Core | Ferrite | |
Inductance | 1.8µH | |
Tolerance | ±10% | |
Current Rating | 390mA | |
Current - Saturation | - | |
Shielding | Shielded | |
DC Resistance (DCR) | 650 mOhm Max | |
Q @ Freq | 50 @ 7.96MHz | |
Frequency - Self Resonant | 60MHz | |
Ratings | - | |
Operating Temperature | -55°C ~ 125°C | |
Frequency - Test | 7.96MHz | |
Mounting Type | Surface Mount | |
Package / Case | 1812 (4532 Metric) | |
Size / Dimension | 0.177" L x 0.126" W (4.50mm x 3.20mm) | |
Height - Seated (Max) | 0.067" (1.70mm) | |
Standard Package | 1,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | CF453215-1R8K | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
CF453215-1R8K is in stock for immediate shipping now. We are the distributor of Bourns Inc. all series components. The condition of CF453215-1R8K is new and unused, you can buy CF453215-1R8K Bourns Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CF453215-1R8K.
