Manufacturer Part Number: | CF-CA-1CB4-P112 |
---|---|
Manufacturer: | Copal Electronics Inc. |
Product Category: | Tactile Switches |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Tactile Switch SPST-NO Side Actuated Surface Mount, Right Angle |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | CF-CA-1CB4-P112 Datasheet |
Internal Part Number | 898-CF-CA-1CB4-P112 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | 3D CAD Models | |
3D Model | CF-CA-1CB4-P112 | |
Category | Switches | |
Family | Tactile Switches | |
Manufacturer | Copal Electronics Inc. | |
Series | CF-CA | |
Packaging | Bulk | |
Part Status | Active | |
Circuit | SPST-NO | |
Switch Function | Off-Mom | |
Contact Rating @ Voltage | 0.05A @ 32VDC | |
Actuator Type | Round Button | |
Mounting Type | Surface Mount, Right Angle | |
Actuator Height off PCB, from Pins | 1.10mm | |
Actuator Orientation | Side Actuated | |
Termination Style | SMD (SMT) Tab | |
Outline | 7.00mm x 6.70mm | |
Illumination | Non-Illuminated | |
Illumination Voltage (Nominal) | - | |
Illumination Type, Color | - | |
Operating Force | 305gf | |
Ingress Protection | - | |
Features | Support Terminal | |
Actuator Material | Resin | |
Switch Travel | 0.25mm | |
Mechanical Life | - | |
Operating Temperature | -40°C ~ 90°C | |
Standard Package | 20 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | CF-CA-1CB4-P112 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
CF-CA-1CB4-P112 is in stock for immediate shipping now. We are the distributor of Copal Electronics Inc. all series components. The condition of CF-CA-1CB4-P112 is new and unused, you can buy CF-CA-1CB4-P112 Copal Electronics Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CF-CA-1CB4-P112.
