| Manufacturer Part Number: | CDB2300-DC-LCO-CP |
|---|---|
| Manufacturer: | Cirrus Logic Inc. |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9013 Pieces |
| Unit Price: | Quote by Email |
| Description: | CS2300 - Timing, Clock Generator Evaluation Board |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | CDB2300-DC-LCO-CP Datasheet |
| Internal Part Number | 898-CDB2300-DC-LCO-CP | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Online Catalog | CS2300 Daughter Card | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Cirrus Logic Inc. | |
| Series | - | |
| Part Status | Active | |
| Main Purpose | Timing, Clock Generator | |
| Embedded | No | |
| Utilized IC / Part | CS2300 | |
| Primary Attributes | Fractional-N, 6 ~ 75MHz Low Jitter Clock Synthesizer, Clock Multiplier | |
| Secondary Attributes | USB, I2C, SPI Interface | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | CDB2300-DC-LCO-CP | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
CDB2300-DC-LCO-CP is in stock for immediate shipping now. We are the distributor of Cirrus Logic Inc. all series components. The condition of CDB2300-DC-LCO-CP is new and unused, you can buy CDB2300-DC-LCO-CP Cirrus Logic Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CDB2300-DC-LCO-CP.
