| Manufacturer Part Number: | CC2560BYFVT |
|---|---|
| Manufacturer: | Texas Instruments |
| Product Category: | RF Transceiver ICs |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IC RF TxRx Only Bluetooth Bluetooth v4.1 2.4GHz |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | CC2560BYFVT Datasheet |
| Internal Part Number | 898-CC2560BYFVT | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Dual-Mode Bluetooth | |
| Design Resources | Development Tool Selector IoT Product Selector | |
| PCN Assembly/Origin | DMOS6 Additional Wafer Fab Site Add 4/Mar/2016 | |
| Online Catalog | CC256x | |
| Category | RF/IF and RFID | |
| Family | RF Transceiver ICs | |
| Manufacturer | Texas Instruments | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Type | TxRx Only | |
| RF Family/Standard | Bluetooth | |
| Protocol | Bluetooth v4.1 | |
| Modulation | GFSK, GMSK | |
| Frequency | 2.4GHz | |
| Data Rate (Max) | 4Mbps | |
| Power - Output | 12dBm | |
| Sensitivity | -95dBm | |
| Memory Size | - | |
| Serial Interfaces | I²S, UART | |
| GPIO | - | |
| Voltage - Supply | 2.2 V ~ 4.8 V | |
| Current - Receiving | 40.5mA ~ 41.2mA | |
| Current - Transmitting | 40.5mA ~ 41.2mA | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | - | |
| Standard Package | 250 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | CC2560BYFVT | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
CC2560BYFVT is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of CC2560BYFVT is new and unused, you can buy CC2560BYFVT Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CC2560BYFVT.
