| Manufacturer Part Number: | C20A1P |
|---|---|
| Manufacturer: | American Electrical Inc. |
| Product Category: | Circuit Breakers |
| Available Quantity: | 9014 Pieces |
| Unit Price: | Quote by Email |
| Description: | CIR BRKR MAG-HYDR 20A 480VAC |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | C20A1P Datasheet |
| Internal Part Number | 898-C20A1P | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | DIN Rail Mounted Circuit Breakers | |
| Video File | American Electrical UL & CSA Approved Fuse Holders and Circuit Breakers | |
| Online Catalog | Circuit Breakers | |
| Category | Circuit Protection | |
| Family | Circuit Breakers | |
| Manufacturer | American Electrical Inc. | |
| Series | - | |
| Part Status | Active | |
| Breaker Type | Magnetic (Hydraulic Delay) | |
| Current Rating | 20A | |
| Voltage Rating - AC | 480V | |
| Voltage Rating - DC | - | |
| Number of Poles | 1 | |
| Actuator Type | Lever | |
| Illumination | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | DIN Rail | |
| Standard Package | 12 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | C20A1P | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
C20A1P is in stock for immediate shipping now. We are the distributor of American Electrical Inc. all series components. The condition of C20A1P is new and unused, you can buy C20A1P American Electrical Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for C20A1P.
